PELLET STOVES

Chapter 5

INSTALLATION AND USE MANUAL

page

57

Maintenance and cleaning

Technical service - Rights reserved MCZ Group S.p.A. - Reproduction prohibited

8.2.1.5.

Sagar Stove Version AIR

1. Lift the hopper cover
2. Remove the ceramic/steatite tile A
3. Remove the tile support B
4. Remove the front grille D by unscrewing the two screws
5. Remove the plug C by unscrewing the screws
6. Remove exchanger E by unscrewing the four screws


Clean and refit all the components using a new front gasket F.

A

B

C

D

E

F

Cleaning the upper exchanger Sagar stove (Air version)
