3.1.7. Technical characteristics
Technical characteristics
CLUB – SUITE – MUSA Mod. AIR
(Max) nominal output power
9,5 kW (8170 kcal/h)
Minimum output power
2,4 kW (2064 kcal/h)
Yield at maximum
91,7%
Yield at minimum
94,1%
Temperature of exhaust smoke at maximum
180°C
Temperature of exhaust smoke at minimum
100°C
Particulate/OGC / Nox (13%O2)
22 mg/Nm3 - 5 mg/Nm3 - 123 mg/Nm3
CO at 13%O
²
at minimum and maximum
0,025 – 0,014%
CO
2
at minimum and maximum
5,7% - 8,7%
Mass of smoke
7,7 g/sec
Recommended draught at Max power
0,10 mbar – 10 Pa
Recommended draught at Min power
0,05 mbar – 5 Pa
Hopper capacity
44 litri
Fuel pellet type
Pellet diametro 6-8 mm. Con pezzatura 5/30 mm.
Pellet consumption per hour
Min~0,6 kg/h* Max~2,0 kg/h*
Operating time between re-fuelling
Al min~48 h* Al max~15 h*
Heatable volume m
3
204/40-233/35-272/30 **
Combustion air inlet
External diameter 50 mm.
Smoke outlet
External diameter 80 mm.
Nominal electrical power (EN 60335-1).
Max. 420 W – Med. 80 W
Power supply frequency and voltage
230 Volt / 50 Hz
Net weight
160 Kg.
Weight with packaging
170 Kg.
Technical characteristics
CLUB – SUITE – MUSA - NIMA Mod. COMFORT AIR
(Max) nominal output power
11,5 kW (9890 kcal/h)
Minimum output power
2,4 kW (2064 kcal/h)
Yield at maximum
90,2%
Yield at minimum
94,1%
Temperature of exhaust smoke at maximum
190°C
Temperature of exhaust smoke at minimum
130°C
Particulate/OGC / Nox (13%O2)
20 mg/Nm3 - 8 mg/Nm3 - 133 mg/Nm3
CO at 13%O
²
at minimum and maximum
0,025 – 0,013%
CO
2
at minimum and maximum
5,7% - 8,6%
Mass of smoke
9,9 g/sec
Recommended draught at Max power
0,10 mbar – 10 Pa
Recommended draught at Min power
0,05 mbar – 5 Pa
Hopper capacity
44 litri
Fuel pellet type
Pellet diametro 6-8 mm. Con pezzatura 5/30 mm.
Pellet consumption per hour
Min~0,6 kg/h* Max~2,2 kg/h*
Operating time between re-fuelling
Al min~48 h* Al max~13 h*
Heatable volume m
3
247/40-283/35-330/30 **
Combustion air inlet
External diameter 50 mm.
Smoke outlet
External diameter 80 mm.
Nominal electrical power (EN 60335-1).
Max. 420 W – Med. 100 W
Power supply frequency and voltage
230 Volt / 50 Hz
Net weight
160 Kg.
Weight with packaging
170 Kg.
* Data that may vary depending on the type of pellets used.
**Heatable volume based on the requested power per m3 (respectively 40-35-30 Kcal/h per m3)
Tested according to EN 14785 accordance with Directive 89/106/EEC (Construction Products).
