PELLET STOVES

Chapter 5

INSTALLATION AND USE MANUAL

page

51

Maintenance and cleaning

Technical service - Rights reserved MCZ Group S.p.A. - Reproduction prohibited

8.2. PERIODIC

CLEANING

BY

A

SPECIALISED

TECHNICIAN

8.2.1. Cleaning of the heat exchanger

After the winter you will need to clean the compartment where

discharge smoke passes.
This cleaning must be done in order to remove all combustion residues

before time and humidity let them harden and make them difficult to

remove.

ATTENTION!
You are advised to contact an authorised MCZ centre
for the cleaning of the upper exchanger.


CLEANING THE UPPER EXCHANGER

When the stove is cold, carry out the following operations to clean the

upper exchanger.

8.2.1.1.

Musa stove (steel sides) COMFORT AIR version

1. Remove the cast iron top.
2. Remove the steel sides A (see par. 3.4.4.)
3. Remove the upper plug L (4 screws)
4. Loosen the front screw of the bracket H; lift the bracket H in a

way to remove the front profile B.

5. Remove the front cast iron grid N with the two brackets M
6. Remove the fan group Q by unscrewing the 7 screws. To easily

remove the screw placed behind the left fan, it is advisable to

loosen the two screws of the fan and move it slightly.

7. To draw the fan group, remove the two front screws of the

cover P, lift it slightly and extract the fans.

8. Remove the exchanger O by unscrewing the 4 screws that

secure it


Clean and refit all the components by using a new front gasket.
