PELLET STOVES

Chapter 3

INSTALLATION AND USE MANUAL

page

24

Installation and assembly

Technical service - Rights reserved MCZ Group S.p.A. - Reproduction prohibited

J

Piedino J

If the stove needs to be connected to a discharge pipe which goes

through the rear wall (to connect up with the flue), take the greatest

care to make sure that the joint is not stressed.
Use the four adjustable feet (J) to get the stove correctly levelled so

that the smoke outlet (S) is lined up with the connecting pipe (H) . The

feet must be adjusted without the ceramic or steel sides, because the

adjustment occurs inside the cladding.

If the smoke outlet of the stove is forced or used

improperly to lift it or position it, the operation of the

stove can be damaged irreparably.

1. Turn the feet clockwise to

lower the stove

2. Turn the feet counter-

clockwise to lower the stove
