PELLET STOVES

Chapter 3

INSTALLATION AND USE MANUAL

page

34

Installation and assembly

Technical service - Rights reserved MCZ Group S.p.A. - Reproduction prohibited

Once both sides are in position it is possible to mount the ceramics or

soapstone on the top.
A ceramic or steatite tile M is secured onto the hopper cover using the

four screws a-b-c-d supplied ( lift the steel cover and secure the tile

internally using screws a-b-c-d) whereas the other one is laid on the

apposite rubbers e-f-g-h found on the top of the stove.

M

N

a

b

c

d

M

e

f

g

h

N
