Installing the Hardware
60 Enterasys X-Pedition 8000/8600 Getting Started Guide
4. Use the #2 Phillips screwdriver to tighten the captive screws on each side of the power supply
to secure it to the chassis.
5. Attach the power cable to the AC power supply.
Installing a DC Power Supply
The X-Pedition DC power supply delivers 3.3, 5, and 12 volts DC to the X-Pedition’s control
module(s), fan modules, and other components. A single DC power supply provides enough current
to operate a fully-configured chassis.
DC Power Supply Specifications
The following table lists the physical specifications for the X-Pedition’s DC power supplies.
Caution: To reduce the risk of electric shock or energy hazards:
1. Connect to a reliably grounded SELV source.
2. The branch circuit over current protection must be rated at a maximum of 20A for the
X-Pedition 8000 and 40A for the X-Pedition 8600.
3. Use 14 AWG solid copper wires on the X-Pedition 8000 and 8 AWG solid copper wires on the
X-Pedition 8600 only.
4. A readily accessible disconnect device that is suitably approved and rated shall incorporated in
the field wiring.
5. To be installed in a restricted access area in accordance with the NEC or authority having
jurisdiction.
X-Pedition 8000 X-Pedition 8600
Input Voltage 48 to 60 Volts
(14 Amperes Max.) 48 to 60 Volts
(27 Amperes Max.)
Output Wattage
At 3.4 V
At 5.1 V
At 12 Volts
390 Watts
70 Amps
25 Amps
2 Amps
780 Watts
140 Amps
50 Amps
4 Amps
Dimensions 2.5 in. H x 7.70 W x 11 D
6.35 cm H x 19.56 W x 27.94 D 5.05 in. H x 7.70 W x 12.28 D
12.83 cm H x 19.56 W x 31.19 D
Weight 6 lbs
2.73 Kg 11 lbs
4.99 Kg
