SSR-ATM29-02
106 Enterasys X-Pedition 8000/8600 Getting Started Guide
SSR-ATM29-02
Connectivity Guidelines
Table 21. SSR-ATM29-02 Recommended Cable Types and Specifications
PHY Card Type Connector
APHY-82V Cat 3,4,5 100 ohm UTP (special pinout) RJ-45
APHY-92V Cat 3,4,5 100 ohm UTP (special pinout) RJ-45
Connector Pin Assignments X-Pedition-APHY-82V and
X-Pedition APHY-92V
Pin Connection
1 Receive analog signal
2 Receive reference
3 Pin used for shield reference if you use a shielded cable and
jumper is enabled
4 Transmit analog positive pulse
5 Transmit analog negative pulse
6 Pin used for shield reference if you use a shielded cable
APHY-22 Cat 3,4,5 100 ohm RJ-45
APHY-21 Multimode Fiber SC
APHY-29IR Single Mode Fiber SC
APHY-67 Co-ax BNC
APHY-77 Co-ax BNC
