Hardware Overview
42 Enterasys X-Pedition 8000/8600 Getting Started Guide
SSR-HSSI-02-CK
The HSSI interface extends the benefits of the X-Pedition router to the WAN, providing
application-level control and wire-speed across high-speed WAN connections. The HSSI interface
supports PPP and Frame Relay at speeds up to 52 Mbps. Typical applications include T3/E3
circuits or inverse multiplexed T1 connections. Flow Rate Limiting, Weighted Random Early
Discard and Weighted Fair Queuing work together to manage and prevent congestion. The SSR-
HSSI-02-CK also provides external clocking—you do not need an external CSU/DSU.
The HSSI module for the X-Pedition supports true Layer 2, 3 and 4 switching, allowing for
consistent policy management for security and quality of service. Detailed accounting information
can be gathered using per-PVC RMON, enabling easy confirmation that service-level agreements
are being met. Prioritization policies can be extended across the entire network to allocate
appropriate resources to groups of users, or specific applications.
Figure 17. Front panel of the SSR-HSSI-02-CK line card
Ports
2 STS-1 or 52 MBps Serial ports
Network Interfaces
50-Pin Connector supporting 1 HSSI interface. WAN INTERFACES V.35, EIA-530, EIA-449, &
X.21.
Physical Dimensions
Size: 52.9 cm H x 2.9 W x 40.1 D (20.83 in. H x 1.14 W x 15.79 D)
Weight: 2.72 kg (6.0 lbs)
Temperature
Operating: 32° to 104° F (0° to 40° C)
Storage: -22° to 194° F (-30° to 90° C)
Humidity
5% to 95% (non-condensing)
Offline
Online
Hot
Swap
SSR-HSSI-02-CK
Link
Rx
Tx
Link
Rx
Tx
Dual HSSI
