Hardware Overview
30 Enterasys X-Pedition 8000/8600 Getting Started Guide
SSR-GLX39-04 and SSR-GSX31-04
The SSR-GLX39-04 and SSR-GSX31-04 are 4-port, T-Series Gigabit Line Cards for the
X-Pedition 8000 and X-Pedition 8600 switch routers. The SSR-GLX39-04 connects to 1000BASE-
LX fiber and the SSR-GSX31-04 connects to 1000BASE-SX fiber.
Note: If your system uses a redundant power configuration or only one power supply, you will
not be able to support more than 4 SSR-GLX39-04 and SSR-GSX31-04 cards in the
X-Pedition 8000 and 10 in the X-Pedition 8600.
Ports
4 1000BASE-SX or 1000BASE-LX SC connectors
Network Interfaces
SC connector—850 nm Short-Wavelength Transceiver
SC connector—1300 nm Long-Wavelength Transceiver
50/125 mm Multimode Fiber-Optic Cables
62.5/125 mm Multimode Fiber-Optic Cables
10/125 mm Single Mode Fiber-Optic Cables
Offline
Online
T
R
L
A
Hot Swap
T
R
L
A
T
R
L
A
T
R
L
A
SSR-GLX39-04
Offline
Online
T
R
L
A
