SSR-GSX31-02
114 Enterasys X-Pedition 8000/8600 Getting Started Guide
SSR-GSX31-02
The SSR-GSX31-02 line card uses SC-style Media Interface Connectors (MICs) to attach to
multimode fiber (MMF) cables.
To attach the segment cables to your SSR-GSX31-02 line card, obtain an MMF cable with an SC
MIC and plug the MIC into the port connector. When you plug the other end of the cable into
another device, ensure that the cable connected to the transmit port on the X-Pedition is connected
to the receive port on the other device. The receive port on the X-Pedition should be connected to
the transmit port on the other device.
Cabling and Connector Specifications
The following table lists the media specifications for the SSR-GSX31-02 (T-Series) line card.
Optics
Table 39. SSR-GSX31-02 Media Specifications
Port Type Specification
1000BASE-SX • 802.3z standard (also uses 802.3x for flow control)
• SC-style Media Interface Connector (MIC); either connection pin in the
MIC can be used for transmit or receive; see SSR-GSX31-02
on page 114
and SSR-HFX21-08-AA and SSR-HFX29-08-AA on page 116 for
information on attaching cables
• 62.5 micron or 50 micron multimode fiber-optic cable
• Maximum 220 or 275 meters (722 or 902 feet) segment length for 62.5
micron fiber-optic cable, based on installed fiber bandwidth
• Maximum 500 or 550 meters (1640 or 1804 feet) segment length for 50
micron fiber-optic cable, based on installed fiber bandwidth
Table 40. SSR-GSX31-02 (1000BASE-SX) 850 nm Fiber
Receiver Sensitivity Transmit Power
Minimum -17 dBm Minimum -9.5 dBm
Maximum 0 dBm Maximum -4 dBm
