Enterasys X-Pedition 8000/8600 Getting Started Guide 121
SSR-HTX32-16
SSR-HTX32-16
Cabling and Connector Specifications
The following table lists the media specifications for the SSR-HTX32-16 (T-Series) line card.
Table 48. SSR-HTX32-16 Media Specifications
Port Type Specification
10BASE-T • 802.3 standard
• RJ-45 connector wired as Media Data Interface Crossed (MDIX); see
Figure 39 for pin assignments
• EIA Category 3, 4, or 5 unshielded twisted pair cabling
• Maximum 100 meters (328 feet) segment length
100BASE-TX • 802.3u standard
• RJ-45 connector wired as Media Data Interface Crossed (MDIX); see
Figure 39 for pin assignments
• EIA Category 5 unshielded twisted pair cabling
• Maximum 100 meters (328 feet) segment length
