Hardware Overview
24
Enterasys X-Pedition 8000/8600 Getting Started Guide
Interface
X-Pedition 8000/8600 2-port base module
Physical Dimensions
Size: 27.94 cm H x 19.68 W x 3.94 D (11.00 in. H x 7.75 W x 1.55 D)
Weight: 1.4 kg (3.0 lb)
Temperature
Operating: 41° to 104°F (5° to 40°C)
Storage: -22° to 164°F (-30° to 73°C)
Humidity
5% to 90% (non-condensing)
LEDs
Table 3. SSR-ATM29-02 LED Indicators
LED
Condition
Status
Hot Swap (2)
Yellow (Top)
Unit is not functioning, cannot hot swap.
Green (Bottom)
Unit is operational.
Port 1 Traffic (2)
Tx Green (Top)
Indicates when the transceiver receives packets.
Rx Green (Bottom)
Indicates when the transceiver receives flow-control
packets.
Port 2 Traffic (2)
Tx Green (Top)
Indicates when the transceiver transmits packets.
Rx Green (Bottom)
Indicates when the transceiver transmits flow-control
packets.
PHY (Top)
Green
The PHY is operating properly and a link is
established.
Yellow
The PHY is inactive due to media errors.
Blinking Green
The PHY was disabled by management.
Off
No connection.
Lightning
(Bottom)
Yellow
The diagnostics have detected a fault.
Blinking Green
The PHY port has been redirected elsewhere.
Off
Unit is operating properly.
