CIRCULAR SLOT (Cycle 254, DIN/ISO: G254) 5.5
5
TNC 320 | User's Manual Cycle Programming | 3/2014
145
Coordinate of workpiece surface Q203 (absolute):
Coordinate of the workpiece surface. Input range
-99999.9999 to 99999.9999
2nd set-up clearance Q204 (incremental):
Coordinate in the spindle axis at which no collision
between tool and workpiece (fixtures) can occur.
Input range 0 to 99999.9999; alternatively
PREDEF
Plunging strategy Q366: Type of plunging strategy:
0: vertical plunging. The plunging angle (ANGLE) in
the tool table is not evaluated.
1, 2: reciprocal plunging. In the tool table, the
plunging angle
ANGLE for the active tool must be
defined as not equal to 0. Otherwise, the TNC
generates an error message
PREDEF: The TNC uses the value from the GLOBAL
DEF block
Feed rate for finishing Q385: Traversing speed of
the tool during side and floor finishing in mm/min.
Input range 0 to 99999.999; alternatively
FAUTO,
FU, FZ
Q351=+1 ;CLIMB OR UP-CUT
Q201=-20 ;DEPTH
Q202=5 ;PLUNGING DEPTH
Q369=0.1 ;ALLOWANCE FOR
FLOOR
Q206=150 ;FEED RATE FOR
PLNGNG
Q338=5 ;INFEED FOR FINISHING
Q200=2 ;SET-UP CLEARANCE
Q203=+0 ;SURFACE COORDINATE
Q204=50 ;2ND SET-UP
CLEARANCE
Q366=1 ;PLUNGE
Q385=500 ;FINISHING FEED RATE
9 L X+50 Y+50 R0 FMAX M3 M99
