HEIDENHAIN TNC 320 373
9.6 Pr
ogr
amming Examples
6 L X+15 Y+10 R0 FMAX M3 Move to starting point for group 1
7 CALL LBL 1 Call the subprogram for the group
8 L X+45 Y+60 R0 FMAX Move to starting point for group 2
9 CALL LBL 1 Call the subprogram for the group
10 L X+75 Y+10 R0 FMAX Move to starting point for group 3
11 CALL LBL 1 Call the subprogram for the group
12 L Z+250 R0 FMAX M2 End of main program
13 LBL 1 Beginning of subprogram 1: Group of holes
14 CYCL CALL Hole 1
15 L IX.20 R0 FMAX M99 Move to 2nd hole, call cycle
16 L IY+20 R0 FMAX M99 Move to 3rd hole, call cycle
17 L IX-20 R0 FMAX M99 Move to 4th hole, call cycle
18 LBL 0 End of subprogram 1
19 END PGM SP1 MM
