Reference Manual
00809-0100-4811, Rev CA
February 2006
6-17
Rosemount 3300 Series
Saving the Transmitter
Configuration The Radar Configuration Tool offers different methods to save the current
transmitter configuration:
• Save only the configuration specified in the Setup window.
• Use the more extensive function in the Memory Map window.
You can use a stored configuration file as a backup of the current
configuration, or it can be distributed for service purposes.
To save the current transmitter setup do the following:
1. Click the Setup icon in the RCT workspace or choose the Setup option
from the View menu to open the Setup window.
2. Click the right mouse button and choose the Receive All option,
or
from the Setup menu choose the Receive All option.
Alternatively, you can use the Receive Page option on each individual
page.
NOTE!
All pages must be received before the setup can be saved.
3. Click the right mouse button and choose the Save Setup option.
4. Choose a destination folder and enter a file name.
5. Click the Save button.
Save Setup
RC
T
-SE
TUP
_
BAS
ICS
_
SAV
ESE
TUP
RCT
-S
AVES
ETUP
FILE
File name
