Reference Manual
00809-0100-4811, Rev CA
February 2006
Rosemount 3300 Series
3-6
MOUNTING
CONSIDERATIONS
Before you install the Rosemount 3300 Series Radar Transmitter, be sure to
consider specific mounting requirements, vessel characteristics and process
characteristics.
Process Connection
The 3300 Series has a threaded connection for easy mounting on the tank
roof. It can also be mounted on a nozzle by using different flanges.
Threaded Connection
Figure 3-2. Mounting on tank
roof using threaded connection
Mounting on tank roof.
Mounting in threaded pipe.
MOUNT THREADE
D
ROOF
M
O
U
N
T
TH
R
E
AD
ED
PI
PE
