Emerson Guided Wave Radar Level and Interface Transmitters 3300 - Manual (Page 113)

Reference Manual
00809-0100-4811, Rev CA
February 2006
A-9
Rosemount 3300 Series
Figure A-7. Coaxial
Dimensions are in inches (millimeter).
L ≤ 20 feet
(6 m)
1.1 (28)
COA
X
IAL.EP
S
s52/s60
G 1/1½ inch
L ≤ 20 feet
(6 m)
1.1 (28)
NPT 1/1½ inch
9.5 (241)
4.3 (110)
6.8 (173)
4.3 (110)
6.8 (173)
4.1 (104)
4.5 (113)
2.4 (62)
½ - 14 NPT
Optional
adapters:
M20x1.5
PG13.5
9.5 (241)
s52
1.1 (27)
NPT 1/1½ inch
1.1 (28)
COAX-
FLANGE
_CA.
EP
9.5 (241)
4.3 (110)
6.8 (173)
4.1 (104)
4.5 (113)
L ≤ 20 feet
(6 m)
Flange
The Hastelloy ® and
Monel ® probes are
designed with a
protective plate.
See also Section 3:
Mechanical
Installation.
For stainless steel,
the probe is welded
to the flange.
15 (381)
HTHP/HP version
