Reference Manual
00809-0100-4811, Rev CA
February 2006
Rosemount 3300 Series
3-12
Insulated Tanks For insulated tanks the permitted ambient temperature is limited above a
certain process temperature. Limitations depend on the thickness of the tank
insulation, see “Ambient Temperature“ on page A-6 for more information.
Figure 3-8. Maximum ambient
temperature vs. process
temperature.
Tank insulation
INSULA
TEDT
ANK.
EP
S
HTHP version
A
M
BI
EN
T_P
R
O
C
_
T
E
M
P.
EP
S
Process
Temperature °F (°C)
Ambient Temperature °F (°C)
