Rosemount 3300 Series
A-16
Code Process Connection - Size / Type (consult factory for other process connections)
ANSI Flanges in 316L SST (ASME A182)
AA 2 inch ANSI, 150 lb
AB 2 inch ANSI, 300 lb
AC 2 inch ANSI, 600 lb (HTHP / HP units)
AD 2 inch ANSI, 900 lb (HTHP / HP units)
AE 2 inch ANSI, 1500 lb (HTHP / HP units)
BA 3 inch ANSI, 150 lb
BB 3 inch ANSI, 300 lb
BC 3 inch ANSI, 600 lb (HTHP / HP units)
BD 3 inch ANSI, 900 lb (HTHP / HP units)
BE 3 inch ANSI, 1500 lb (HTHP / HP units)
CA 4 inch ANSI, 150 lb
CB 4 inch ANSI, 300 lb
CC 4 inch ANSI, 600 lb (HTHP / HP units)
CD 4 inch ANSI, 900 lb (HTHP / HP units)
CE 4 inch ANSI, 1500 lb (HTHP / HP units)
DA 6 inch ANSI, 150 lb
EN (DIN) Flanges in 316L SST (EN 1.4404)
HB DN50, PN40
HC DN50, PN64 (HTHP / HP units)
HD DN50, PN100 (HTHP / HP units)
IA DN80, PN16
IB DN80, PN40
IC DN80, PN64 (HTHP / HP units)
ID DN80, PN100 (HTHP / HP units)
JA DN100, PN16
JB DN100, PN40
JC DN100, PN64 (HTHP / HP units)
JD DN100, PN100 (HTHP / HP units)
KA DN150, PN16
Threaded Connections
RA 1 ½ inch NPT thread
RB 1 inch NPT thread (only available for probe type 3B and 4A)
SA 1 ½ inch BSP (G 1 ½ inch) thread
SB 1 inch BSP (G 1 inch) thread (only available for probe type 3B and 4A)
Proprietary Flanges.
TF Fisher - proprietary 316 Stainless Steel (for cage 249B) Torque Tube Flange
TT Fisher - proprietary 316 Stainless Steel (for cage 249C) Torque Tube Flange
TM Masoneilan - proprietary 316 Stainless Steel Torque Tube Flange
