Reference Manual
00809-0100-4811, Rev CA
February 2006
Rosemount 3300 Series
www.rosemount.com
Section 4 Start-Up
Safety messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4-1
Configuration Parameters . . . . . . . . . . . . . . . . . . . . . . . . . page 4-2
Configuration using a 375 Field Communicator . . . . . . . page 4-7
Configuration using The Radar Configuration Tool . . . . page 4-14
Special Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4-24
SAFETY MESSAGES Procedures and instructions in this section may require special precautions to
ensure the safety of the personnel performing the operations. Information that
raises potential safety issues is indicated by a warning symbol (
). Refer to
the safety messages listed at the beginning of each section before performing
an operation preceded by this symbol.
Explosions could result in death or serious injury:
Verify that the operating environment of the gauge is consistent with the appropriate
hazardous locations certifications.
Before connecting a HART-based communicator in an explosive atmosphere, make
sure the instruments in the loop are installed in accordance with intrinsically safe or
non-incendive field wiring practices.
Do not remove the gauge cover in explosive atmospheres when the circuit
is alive.
Failure to follow safe installation and servicing guidelines could result in death or
serious injury:
Make sure only qualified personnel perform the installation.
Use the equipment only as specified in this manual. Failure to do so may impair the
protection provided by the equipment.
Do not perform any service other than those contained in this manual unless you are
qualified.
