Rosemount 3300 Series
A-12
ORDERING INFORMATION
Model Code 3301, Level in Liquids
Model Product Description
3301 Guided Wave Radar Level Transmitter (interface available for fully immersed probe)
Code Signal Output
H 4-20 mA with HART ® communication
Code Housing Material
A Polyurethane-covered Aluminum
Code Conduit / Cable Threads
1 ½ - 14 NPT
2 M20 x 1.5 adapter
3 PG 13.5 adapter
Code Operating Temperature and Pressure
S - 15 psig (-1bar) to 580 psig (40 bar) @ 302 °F (150 °C) (1)
H High Temp / High Pressure (2) : 2940 psi @ 750 °F and 5000 psi @ 100 °F (203 bar @ 400 °C and 345 bar @ 38 °C) according
to ANSI Class 2500 (Probe Type 3A, 3B and 4A)
P High Pressure (2) . Max 500 °F (200 °C): 3500 psi @ 500 °F and 5000 psi @ 100 °F (243 bar @ 200 °C and 345 bar @ 38 °C)
according to ANSI Class 2500 (Probe Type 3A, 3B and 4A)
Code Material of Construction (3) : Process Connection / Probe
1 316 / 316 L SST (EN 1.4404)
2 Hastelloy ® C-276 (UNS N10276). Available for probe type 3A, 3B and 4A.
3 Monel ® 400 (UNS N04400). Available for probe type 3A, 3B and 4A
7 PTFE covered probe and flange. Available for probe type 4A and 5A, Flanged versions
8 PTFE covered probe. Available for probe type 4A and 5A
Code Sealing, O-ring Material (Consult factory for other o-ring materials)
N None (4)
V Viton ® fluoroelastomer
E Ethylene Propylene
K Kalrez ® 6375 perfluoroelastomer
B Buna-N
Code Probe Type Process Connection Probe Lengths
1A Rigid Twin Lead Flange or 1.5 inch Thread Min: 1 ft 4 in. (0.4 m). Max: 9 ft 10 in. (3 m)
2A Flexible Twin Lead with weight Flange or 1.5 inch Thread Min: 3 ft 4 in. (1 m). Max: 77 ft 1 in. (23.5 m)
3A Coaxial Flange, 1 or 1.5 inch Thread Min: 1 ft 4 in. (0.4 m). Max: 19 ft 8 in. (6 m)
3B Coaxial, perforated for easier cleaning Flange, 1 or 1.5 inch Thread Min: 1 ft 4 in. (0.4 m). Max: 19 ft 8 in. (6 m)
4A Rigid Single Lead Flange, 1 or 1.5 inch Thread Min: 1 ft 4 in. (0.4 m). Max: 9 ft 10 in. (3 m)
5A Flexible Single Lead with weight Flange, 1 or 1.5 inch Thread Min: 3 ft 4 in. (1 m). Max: 77 ft 1 in. (23.5 m)
5B Flexible Single Lead with chuck (5) Flange, 1 or 1.5 inch Thread Min: 3 ft 4 in. (1 m). Max: 77 ft 1 in. (23.5 m)
Code Probe Length Units
E English (feet, inch)
M Metric (meters, centimeters)
Code Total Probe Length (6) (feet/m)
xx 0 - 77 ft or 0-23 m
Code Total Probe Length (6) (inch/cm)
xx 0 - 11 inch or 0-99 cm
