Reference Manual
00809-0100-4811, Rev CA
February 2006
A-21
Rosemount 3300 Series
Code Process Connection - Size/Type (consult factory for other process connections)
ANSI Flanges in ASME A182 Gr. F316L SST
AA 2 inch ANSI, 150 lb
AB 2 inch ANSI, 300 lb
AC 2 inch ANSI, 600 lb (HTHP / HP)
AD 2 inch ANSI, 900 lb (HTHP / HP)
AE 2 inch ANSI, 1500 lb (HTHP / HP)
BA 3 inch ANSI, 150 lb
BB 3 inch ANSI, 300 lb
BC 3 inch ANSI, 600 lb (HTHP / HP)
BD 3 inch ANSI, 900 lb (HTHP / HP)
BE 3 inch ANSI, 1500 lb (HTHP / HP)
CA 4 inch ANSI, 150 lb
CB 4 inch ANSI, 300 lb
CC 4 inch ANSI, 600 lb (HTHP / HP)
CD 4 inch ANSI, 900 lb (HTHP / HP)
CE 4 inch ANSI, 1500 lb (HTHP / HP)
DA 6 inch ANSI, 150 lb
EN (DIN) Flanges in 10222-5-1.4404 SST
HB DN50, PN40
HC DN50, PN64 (HTHP / HP)
HD DN50, PN100 (HTHP / HP)
IA DN80, PN16
IB DN80, PN40
IC DN80, PN64
ID DN80, PN100
JA DN100, PN16
JB DN100, PN40
JC DN100, PN64 (HTHP / HP)
JD DN100, PN100 (HTHP / HP)
KA DN150, PN16
Proprietary Flanges
TF Fisher - Proprietary 316 Stainless Steel (for cage 249B) Torque Tube Flange. Outer diameter: 9.0 in. (228.6 mm).
TT Fisher - Proprietary 316 Stainless Steel (for cage 249C) Torque Tube Flange. Outer diameter: 5.7 in. (144.5 mm).
TM Masoneilan - Proprietary 316 Stainless Steel Torque Tube Flange. Outer diameter: 7.5 in. (191 mm).
Threaded
RA 1.5 inch NPT thread
RB 1 inch NPT thread (only available for probe type 3A, 3B, 4A, 5A, 5B)
SA 1½ inch BSP (G 1½ inch) thread
SB 1 inch BSP (G 1 inch) thread (only available for probe type 3A, 3B, 4A, 5A, 5B)
Antenna with plate design for customer supplied flange
PA Antenna with 2 in. / DN50 plate
PB Antenna with 3 in. / DN80 plate
PC Antenna with 4 in. / DN100 plate
PD Antenna with 6 in. / DN150 plate
PE Antenna with 8 in. / DN200 plate
