87
Maintenance
Electrical Precautions
Be aware of the following precautions regarding the electrical system to avoid disruption of
electrical signals and possible system malfunction.
DO:
• DO use ONLY genuine VICTORY parts and accessories designed for your model and
follow the instructions provided.
• DO use the accessory power jack provided (if equipped).
• If it is necessary to provide power to an item that does not use one of the previously
mentioned power jacks, connect to the load side of the main circuit breaker (under the
cover behind the oil cooler), and connect the ground wire to the engine ground at the front
left side of the crankcase (near the circuit breaker).
DO NOT:
• DO NOT splice or cut any wires.
• DO NOT tap in to any power or ground on the motorcycle unless specifically directed to
do so by the VICTORY instructions that come with the kit.
• DO NOT back-probe electrical connectors on the vehicle unless directed to do so by the
Service Manual.
• DO NOT power any accessories from the diagnostic connector (under left side cover).
Engine Compression Test
An engine compression test can be performed to monitor general engine condition. See the
VICTORY Service Manual or your authorized VICTORY dealer.
Exhaust System Inspection
Check the exhaust system for stains from leaking exhaust gasses. Replace damaged or
leaking exhaust gaskets. See the VICTORY Service Manual or your authorized VICTORY
dealer.
Check all exhaust system fasteners. Tighten loose clamps and fasteners. Do not overtighten.
Fastener Torques
1. 12 ft-lbs (16 Nm)
2. 35 ft-lbs (47.5 Nm)
3. 8 ft-lbs (11 Nm)
4. 35 in-lbs (4 Nm)
5. 18 ft-lbs (24 Nm)
2
3
4
3
1
5
5
2
2
