Grass Valley NV9654 v.1.1 - Manual (Page 99)

89
NV9654
User’s Guide
Environmental Specifications
Table provides environmental specifications for the NV9654.
Defaults
Initial Panel State
Multi-destination mode or X-Y mode, selectable.
Destination: the configured default.
Buttons: high-tally is maximum brightness; low-tally is low brightness.
Configuration Page
The initial button page for a new NV9654 configuration is empty:
No button pages are defined other than the default.
The default panel options are:
Behavioral model: All-Buttons.
Panel mode: Multi-destination.
Release mode: Normal.
Default destination: None.
Preset Monitor: None
Status Monitor: None
XY Data Routing: Automatic.
MD Data Routing: Automatic.
Default name set: System names
Multidest Device Limit:8. (This is the lowest value. The upper limit is 512.)
Src/Dst Immediate TakeEnabled (checkbox checked).
All other options: Disabled (check boxes clear).
The tally inputs and outputs are all initially undefined.
NV9654 Environmental Specifications
Specification Detail
Operating temperature 0–40°C, ambient.
Relative humidity 0 to 90%, non-condensing.
Cooling No fan required.
