80
Operation
Setup Mode
In the setup menu, press the ‘Panel Test Mode’ button. One button appears:
Press the ‘Push to Test’ button repeatedly to execute the test.
Each time you press the button, the panel illuminates all its LCD buttons in a single color,
changing the color each time you press the button. Keep pressing the button until all 7 col-
ors (high and low tally) have been displayed.
The panel test shows you (1) whether all the buttons are working and how well and (2)
whether the software and firmware are working.
When you are finished using the setup menu, press ‘Exit’ one or more times to return the panel
to its normal pre-connected state.
When you connect the panel to its network, the panel leaves its setup state and begins to
initialize in its normal operational state. After a short time, the panel will have initialized to its
configured state and will display its default button page.
PUSH PUSH
TO TO
TEST TEST
• • •
