3-48
Section 3 Ð Editor Interface Commands
5. The editor re-sends a block of 250 bytes to the switcher:
6. The switcher sends a request for next block to the editor:
7. The editor sends the final block to the switcher:
8. The switcher sends a final request message to the editor, acknowledging
receipt of the last block and ending the transfer:
NOTE: It is not possible for the editor or the switcher to request a re-send of the
last block.
Byte
Count Effects
Address Command
Code Sequence
Number Register
Number E-MEM
Data
FFH 01 DEH 00H 01H 21H 250 bytes of E-MEM data
Byte
Count Effects
Address Command
Code Sequence
Number Register
Number E-MEM
Data
05 01 5EH 00H 02H 21H none
Byte
Count Effects
Address Command
Code Sequence
Number Register
Number E-MEM
Data
8C 01 DEH FFH FEH 21H 135 bytes of E-MEM data
Byte
Count Effects
Address Command
Code Sequence
Number Register
Number E-MEM
Data
05 01 DEH FFH FEH 21H none
