3-10
Section 3 Ð Editor Interface Commands
Crosspoint Bus (C4) Command (KEY 2/DSK 2)
The Write Crosspoint Bus command enables the editor to select any crosspoint on
a bus speciÞed by the effects address, and the command code.
Table 3-6. Crosspoint Bus Command
Effects Addresses
Valid effects addresses for the Crosspoint Bus command are as follows:
EFFECTS ADDRESS ASSIGNMENTS
01 Mix/Effects 1 (KEY 2)
02 Mix/Effects 2 (KEY 2)
03 Mix/Effects 3 (KEY 2)
04 DSK 2
Crosspoint Numbers
Valid crosspoint numbers are shown in Table 3-3, ÒCommon Crosspoint Numbers
for All Buses,Ó on page 3-7.
Function
Byte
Count Effects
Address Command
Code
Message
Write Crosspoint Bus 03 EX C4 (Write) Crosspoint #
