Section 3 Ð Editor Interface Commands
5. The editor sends a request for the next block to the switcher:
6. The switcher sends another 250 bytes of data to the editor:
7. The editor sends a request for the next block to the switcher:
8. The switcher sends another 250 bytes of data to the editor:
9. The editor sends a request for the next block to the switcher:
10. The switcher sends another 250 bytes of data to the editor:
11. The editor sends a request for the next block to the switcher:
Byte
Count Effects
Address Command
Code Sequence
Number Register
Number E-MEM
Data
05 01 5EH 00H 02H 21H none
Byte
Count Effects
Address Command
Code Sequence
Number Register
Number E-MEM
Data
FFH 01 DEH 00H 02H 21H 250 Bytes of E-MEM data
Byte
Count Effects
Address Command
Code Sequence
Number Register
Number E-MEM
Data
05 01 5EH 00H 03H 21H none
Byte
Count Effects
Address Command
Code Sequence
Number Register
Number E-MEM
Data
FFH 01 DEH 00H 03H 21H 250 bytes of E-MEM data
Byte
Count Effects
Address Command
Code Sequence
Number Register
Number E-MEM
Data
05 01 5EH 00H 04H 21H none
Byte
Count Effects
Address Command
Code Sequence
Number Register
Number E-MEM
Data
FFH 01 DEH 00H 04H 21H 250 bytes of E-MEM data
Byte
Count Effects
Address Command
Code Sequence
Number Register
Number E-MEM
Data
05 01 5EH 00H 05H 21H none
