Crosspoint Bus (C3) Command (KEY 1/DSK 1)
Crosspoint Bus (C3) Command (KEY 1/DSK 1)
The Write Crosspoint Bus command enables the editor to select any crosspoint on
a bus speciÞed by the effects address, and the command code.
Table 3-5. Crosspoint Bus Command
Effects Addresses
Valid effects addresses for the Crosspoint Bus command are as follows:
EFFECTS ADDRESS
ASSIGNMENTS
01
Mix/Effects 1 (KEY 1)
02
Mix/Effects 2 (KEY 1)
03
Mix/Effects 3 (KEY 1)
04 DSK
1
Crosspoint Numbers
Valid crosspoint numbers are shown in Table 3-3, ÒCommon Crosspoint Numbers
for All Buses,Ó on page 3-7.
Function
Byte
Count
Effects
Address
Command
Code
Message
Write Crosspoint Bus
03
EX
C3 (Write)
Crosspoint #
