3-39
Write Split Key (E4) Command
EFFECTS ADDRESS ASSIGNMENTS
00 PGM-PST Mix System
01 Mix/Effects 1 System
02 Mix/Effects 2 System
03 Mix/Effects 3 System
04 Downstream Keyer (DSK)
07 DPM 1
08 DPM 2
09 DPM 3
0A DPM 4
Crosspoint Numbers
Valid crosspoints for this command are shown in the following table:
Table 3-21. Split Key Command Crosspoints
The Þll crosspoint is a valid crosspoint in hex.
The format of the Key Crosspoint byte is as follows:
Address Description
01H–30H = Normal Crosspoints 1 to 48 M/E 1, 2, 3 and DSK
31H = M/E 1 M/E 2 and M/E 3 and DSK
32H = M/E 2 M/E 1 and M/E 3 and DSK
33H = M/E 3 M/E 1 and M/E 2 and DSK
Bit Bit
7 6 5 4 3 2 1 0
A/V 0 X X X X X X
Valid Crosspoint (00H to 34H)
0 =
Auto Select Mode
1 = Video Select Mode
