Section 3 Ð Editor Interface Commands
The format of the HD byte is as follows:
The format of the TN byte is as follows:
The format of the UN byte is as follows:
(1) Not supported in Version 5.0 and earlier
If bit 6 (set Key 1 rate only) and bit 7 (set Key 2 rate only) are both zero, then both
the Key 1 and Key 2 rates will be set by the command.
1
If bits 6 and 7 are both set to 1, then only Key 1 rate will be set.
1. Only Key 1 rate set in Version 5.0 and earlier.
Bit Bit
7 6 5 4 3 2 1 0
X 0 0 0 X X X X
Rate value of 0 through 9 in BCD (0000 to 1001)
0 = Set rate only, do not perform the transition.
1 = Set rate and perform the auto transition.
Bit Bit
7 6 5 4 3 2 1 0
0 0 0 0 X X X X
Rate value of 0 through 9 in BCD (0000 to 1001)
Bit Bit
7 6 5 4 3 2 1 0
X X 0 0 X X X X
Rate value of 0 through 9 in BCD (0000 to 1001)
1 = Set Key 1 rate only (1)
1 = Set Key 2 rate only (1)
