3-6
Section 3 Ð Editor Interface Commands
Crosspoint Bus (C1) Command (PGM/BKGD A/AUX)
The Write Crosspoint Bus command enables the editor to select any crosspoint on
a bus speciÞed by the effects address, and the command code.
Table 3-2. Crosspoint Bus Command
Effects Addresses
Valid effects addresses for the Crosspoint Bus command are as follows:
EFFECTS ADDRESS ASSIGNMENTS
00 PGM-PST System (PGM)
01 Mix/Effects 1 (BKGD A)
02 Mix/Effects 2 (BKGD A)
03 Mix/Effects 3 (BKGD A)
0C Aux Bus 1A
0D Aux Bus 1B
0E Aux Bus 2A
0F Aux Bus 2B
10 Aux Bus 3A
11 Aux Bus 3B
12 Aux Bus 4A
13 Aux Bus 4B
14 Aux Bus 5A
15 Aux Bus 5B
16 Aux Bus 6A
17 Aux Bus 6B
18 Aux Bus 7A
19 Aux Bus 7B
1A Aux Bus 8A
1B Aux Bus 8B
1C Aux Bus 9A
1D Aux Bus 9B
Function
Byte
Count Effects
Address Command
Code
Message
Write Crosspoint Bus 03 EX C1 (Write) Crosspoint #
