3-7
Crosspoint Bus (C1) Command (PGM/BKGD A/AUX)
Crosspoint Numbers
Valid crosspoint numbers are as follows:
(1) Accessible only on AUX buses, PVW bus, and MASK bus
(2) Accessible only on PVW bus
Table 3-3. Common Crosspoint Numbers for All Buses
Crosspoint Name Number Crosspoint Name Number
Crosspoint 1 01H Crosspoint 29 1DH
Crosspoint 2 02H Crosspoint 30 1EH
Crosspoint 3 03H Crosspoint 31 1FH
Crosspoint 4 04H Crosspoint 32 20H
Crosspoint 5 05H Crosspoint 33 21H
Crosspoint 6 06H Crosspoint 34 22H
Crosspoint 7 07H Crosspoint 35 23H
Crosspoint 8 08H Crosspoint 36 24H
Crosspoint 9 09H Crosspoint 37 25H
Crosspoint 10 0AH Crosspoint 38 26H
Crosspoint 11 0BH Crosspoint 39 27H
Crosspoint 12 0CH Crosspoint 40 28H
Crosspoint 13 0DH Crosspoint 41 29H
Crosspoint 14 0EH Crosspoint 42 2AH
Crosspoint 15 0FH Crosspoint 43 2BH
Crosspoint 16 10H Crosspoint 44 2CH
Crosspoint 17 11H Crosspoint 45 2DH
Crosspoint 18 12H Crosspoint 46 2EH
Crosspoint 19 13H Crosspoint 47 2FH
Crosspoint 20 14H Crosspoint 48 30H
Crosspoint 21 15H M/E 1 31H
Crosspoint 22 16H M/E 2 32H
Crosspoint 23 17H M/E 3 33H
Crosspoint 24 18H PGM Out 34H (1)
Crosspoint 25 19H M/E 1 PVW 35H (2)
Crosspoint 26 1AH M/E 2 PVW 36H (2)
Crosspoint 27 1BH M/E 3 PVW 37H (2)
Crosspoint 28 1CH DSK PVW 38H (2)
