Kayak — User Manual 511
Installation Menus
Misc Index Card
Index card for performing global panel settings and fader adjustment.
Figure 422. Sidepanel – Index Card AUX Global
Fader/Joystick Adjustment:
Adjustment of the fader end-position values (fine adjustment of the A/D
converters). Lower end-position: 0% signal, Upper end-position: 100%
signal. End-position means: Move the fader gently as far as it will go.
During fader adjustment moving the fader does not affect video signals.
1. Press Modify, a pop-up menu with dialog messages appears.
2. Move all faders to the upper end-position and select the menu entry in
the pup–up menu. Move all faders to the upper position and press OK.
3. Move all faders to the lower end-position and select the entry in the
pop–up menu. Move all faders to the lower position and press OK. The
automatic adjustment is finished.
