KAM-ENC-2AES Instruction Manual

51

KAM-ENC-2AES Links and Web Pages

Audio Sync Web Page

Use the Audio Sync web page (

Figure 31 on page 52

) to:

Synchronize the two audio channel pairs to video Frame Sync, and/or

Add audio delay using the delay adjust controls to add delay to each
channel or lock the channels together as a pair and adjust delay.

Enable Auto Track

Select the

On

checkbox to enable auto tracking to synchronize the audio pair

to the video frame sync. The amount of auto tracking applied is shown in
the Auto Tracking Delay read-only display.

The total amount of delay is reported in the Total Delay read-only display
for each channel.

Delay Adjustments

Each audio channel can be adjusted for delay separately or in pairs. Use the
following adjustments for audio delay:

To lock the two channels in a pair together, select the

Channel Lock

checkbox for Pair 1 or Pair 2.

Adjust the delay for each channel with the Ch A Delay Adjust and Ch B
Delay adjust controls for each pair. If the pair is locked, adjusting either
control will set the delay to the same value for each channel in the pair.

Use
this
link
