16 KAM-ENC-2AES Instruction Manual
Configuration and Adjustments
Freeze mode selection (Internal timing
source)
None
None, AutoBlack,
AutoFreeze, Field 1,
Field 2, or Frame
Frame Sync/
Freeze Mode Selection radio buttons
N/A
Enable video processing Enable
Disable, Enable,
or Color Bars
Video Proc/
Video Processing radio buttons
N/A
Video gain lock Off On or Off
Video Proc/
Video Gain Lock radio buttons
N/A
Main video contrast/Y gain 100%
50 to 149.6%
(0.4% steps)
Video Proc/Standard View
Y Gain control (%)
YGain
Main video chroma gain 100%
50 to 149.6%
(0.4% steps)
Video Proc/Standard View
Chroma Gain control (%)
ChroGain
Enable Clip controls Disable Enable or Disable
Video Proc/Standard View
Clip Settings radio buttons
N/A
Apply clips to VBI Off On or Off
Video Proc/Standard View
Apply Clips to VBI checkbox
N/A
Main video soft/Y black clip -6.8%
-6.8 to 109%
(0.1% steps)
Video Proc/Standard View
Soft/Y Black Clip control (%)
YBClip
Main video hard/video black clip
-37.3% (525)
-30.0% (625)
-37.3 to -7.3% (525)
-30.0 to 0% (625)
(0.1% steps)
Video Proc/Standard View
Hard/Video Black Clip control (%)
VBClip
Main video soft/Y white clip 109%
-6.8 to 109%
(0.1% steps)
Video Proc/Standard View
Soft/Y Clip control (%)
YWClip
Main video hard/video white clip 138.7%
-6.8 to 138.7%
(0.1% steps)
Video Proc/Standard View
Hard/Video Clip control (%)
VidWClip
Main video brightness/Y offset 0%
-3.55 to 3.44%
(0.11% steps)
Video Proc/Advanced View
Brightness/Y Offset control (%)
YOffset
Main video hue/chroma phase 0.0
± 89.8 degrees
(0.1 degree steps)
Video Proc/Advanced View
Hue/Phase control (degrees)
ChroPhs
Main video B-Y gain 100%
50 to 149.6%
(0.4% steps)
Video Proc/Advanced View
B-Y Gain control (%)
BYGain
Main video B-Y balance/offset 0.0
-3.55 to 3.44%
(0.11% steps)
Video Proc/Advanced View
B-Y Balance/Offset control (%)
N/A
Main video R-Y gain 100%
50 to 149.6%
(0.4% steps)
Video Proc/Advanced View
R-Y Gain control (%)
RYGain
Main video R-Y balance/offset 0.0
-3.55 to 3.44%
(0.11% steps)
Video Proc/Advanced View
R-Y Balance/Offset control (%)
N/A
Blank SDI VBI lines (line-by-line) Not Blanked Blank/Not Blanked
VBI SDI/
Field 1/Field 2 Blank VBI line checkboxes
N/A
VBI encoding add setup (525 only) Add Setup or No Setup
VBI Encode/
Check corresponding line Setup checkbox
N/A
Add setup to composite output Setup Setup or No Setup
Composite Out/
Setup or No Setup radio button
N/A
Cross Color Removal (composite out) Disable Enable or Disable
Composite Out/
Cross Color Removal
Disable or Enable radio button
N/A
Chrominance Signal (composite out) Enable Enable or Disable
Composite Out/
Chrominance Signal
Disable or Enable radio button
N/A
Table 3. Summary of KAM-ENC-2AES Configuration Controls
Function Default
Range/Choices
Resolution
Web Page/
Function Name
Newton
Panel
