KAM-ENC-2AES Instruction Manual

25

KAM-ENC-2AES Links and Web Pages

Status Web Page

The Status web page for the KAM-ENC-2AES module (

Figure 11 on

page 26

) provides an overall indication of the health of the system and links

to web pages for the active components:

Status Header – the same on all Kameleon configuration pages (see

Web

Page Operations and Functional Elements on page 22

),

Color-coded communication status for each component and path,

Summary of all fault/warning conditions, and

Textual module status, front module, and submodule properties.

Color-coded Status Indicators and Links

Each box represents a Kameleon module or submodule as indicated in

Figure 11 on page 26

. Arrows represent signal paths that may or may not

be monitored. These elements act as links when their function is active
(indicated by underlined function name).

Color code:

Green = Pass – operating as expected.

Yellow = Warning – signal is absent, has errors, or is misconfigured.

Red = Fault – a component has failed.

Grey = Not monitored.

White = Not present.

Status/Front Module Properties

The Status/Front Module properties in the footer provide a textual
summary of the color-coded module status. Front module properties
provide hardware, firmware, software identification, and asset tag number
for the KAM-ENC-2AES module. Presence and status of any submodules
is also reported.
