KAM-ENC-2AES Instruction Manual

15

Configuration and Adjustments

Configuration and Adjustments

KAM-ENC-2AES configuration and monitoring can be performed using a
web browser GUI interface or a networked Newton Control Panel. This
section provides an overview of each of these controls along with the con-
figuration parameters available with each type of control device.

Configuration Summary

The configuration parameters and monitoring functions available with the
web browser interface and the Newton Control Panel are summarized in

Table 3

. The parameter defaults, choices, ranges, and resolution are pro-

vided for each function

Table 3. Summary of KAM-ENC-2AES Configuration Controls

Function

Default

Range/Choices

Resolution

Web Page/

Function Name

Newton

Panel

Set KAM-AES-R rear module audio inputs

Unbalanced

Unbalanced or Balanced

I/O Config/

Unbalanced or Balanced radio button

N/A

Set KAM-AES-R rear module audio outputs

Unbalanced

Unbalanced or Balanced

I/O Config/

Unbalanced or Balanced radio button

N/A

SDI In web page view selection

Summary

Summary or Detail

SDI In/

Summary or Detail radio button

N/A

Set error reporting for SDI input video

Enabled

Enabled or Disabled

SDI In/Detail View/

Check or uncheck error checkboxes

N/A

Input status loss of signal report

Enable

Enable or Disable

Video Input Select/

Input Status Report Loss of Signal

checkbox

N/A

Select video line rate

Auto

525, 625, or Auto

Video Input Select/

Video Line Rate radio button

N/A

Frame Reference loss of signal status

Report

Report or No Report

Video Input Select/

Frame Reference Report Loss of Signal

checkbox

N/A

SDI Input Error warning status

Warn SDI

Errors

Warn SDI Errors or

No Warning

Video Input Select/

SDI Input Errors Warn SDI Errors

Warn SDI Errors checkbox

N/A

Select output timing source

Video In

Video In or

Internal Frame Reference

Video Input Select/

Output Timing Selection radio buttons

N/A

Define VBI data lines

None

525: None, 21/284,

22/285, 23/286 or 24/287

625: None, 24/337,

25/338, 26/339 or 27/340

or 28/341

Video Input Select/

Advanced (VBI Config) radio button

VBI/Data Lines Last Data Line radio button

N/A

Main video horizontal timing adjustment

0

525: 0 to 857.5 pixels

625: 0 to 863.5

(0.5 pixel steps)

Frame Sync/

HTiming control (pixels)

HTiming

Main video vertical timing adjustment

0

525: 0 to 524 lines
625: 0 to 624 lines

(1 line steps)

Frame Sync/

VTiming control (Lines)

VTiming

Freeze mode selection (Video In timing
source)

None

None, Field 1, Field 2,

or Frame

Frame Sync/

Freeze Mode Selection radio buttons

N/A
