KAM-ENC-2AES Instruction Manual

27

KAM-ENC-2AES Links and Web Pages

Warning/Fault Summary

The following warnings and faults are reported in the summary section
(refer to

Figure 11 on page 26

). A

Fault

indicates a serious condition that pro-

hibits proper operation. A

Warning

indicates a condition which may or may

not adversely affect operating conditions, but should be noted. Usually
warnings are something the user can correct by changing configuration,
settings or input signals.

Warnings

WARNING - Rear Module is not connected

WARNING - Wrong Rear Module (incompatible with Kameleon)

WARNING - Wrong Rear Module (no communication)

WARNING - Wrong Rear Module (unknown type, incompatible)

WARNING - Video Input is 625 and reference is 525 lines

WARNING - Video Input is 525 and reference is 625 lines

WARNING - Video Input is 625 but configuration is 525 lines

WARNING - Video Input is 525 but configuration is 625 lines

WARNING - Video Input Signal not detected

WARNING - Frame Reference is not present

WARNING - Frame Reference is not locked to input

WARNING - Frame Reference is not present

WARNING - No Video output - GenLock selected but not present

WARNING - 1 or more Audio Input signals not detected

Internal Error - Unknown sub module type

Faults

FAULT - nnV power supply bad. (nn = variable: 24 V, 12.5 V, 5 V,
3.3 V, 1.5 V, -5 V, or -12.5 V)

FAULT - A/D failed (A to D system measuring power supplies and bus
levels)

FAULT - Xilinx 1 failure (main video processor)

FAULT - Xilinx 2 failure (main audio processor)

FAULT - MFM (Multi-function module) EEPROM checksum fails

FAULT - DS1803 not responding (digital potentiometer for video in
adjustment)

FAULT - TMC22051A not responding (composite input decoder)

Internal Error - Unknown front module type
