30

KAM-ENC-2AES Instruction Manual

KAM-ENC-2AES Links and Web Pages

Header Row

The top header row provides the connector hardware physical label (J#)
and the dedicated signal type for the connector. This information is deter-
mined by the type of rear module and front processor module installed
(refer to the

Functional View Web Page on page 31

).

Connectors

The connector row illustrates connector type provided (BNC or 3-pin ter-
minal) for each port. For this rear module, one SDI video input, two digital
audio outputs, and one composite video output are provided.

Input/Output Mode

I/O mode is either static read-only or an operational Input/Output selec-
tion (determined by the rear module used).

Signal Name

Enter a signal name (up to 15 characters) for each operational
input/output. The name will be used to identify the signal in other config-
uration web pages. Factory default names are shown in

Figure 12 on

page 28

and

Figure 13 on page 29

.

Status

Table 4

shows, by color and signal type, the signal status reports that may

be displayed in the Status row for this module configuration:

Table 4. I/O Config Status Report Messages

Color

Video In

Analog Audio In

Analog Audio Out

Digital Audio In

Digital Audio Out

Video Out

Green

Present

None

None

Present

None

None

Yellow

Not present or

525/625 mismatch

None

None

Not Present

None

None

Light Grey

None

None

None

None

Not Monitored

Not Monitored

Medium Grey

None

None

None

Not Available

Not Available

None

Dark Grey

None

None

None

None

None

None
