8943CF — Instruction Manual
Configuration and Monitoring
The local configuration controls are described below and shown in
for the switch settings to set each
parameter.
•
Function (rotary) switch (S2) – this switch is used to access each of the
four channels for configuration. The switch has 16 possible positions (0
through 9 and A through F). Only positions 1, 2, 3, 4, and F are used (see
). Bank 2 is also not used in this application.
•
Paddle switch (S1) – scrolls through the available modes for the selected
channel when the switch is held momentarily in either the up or down
position.
•
CONFIG (configuring) LED – when on, indicates the module is initial-
izing or processing configuration information.
Note
When configuration is complete, the Function switch should be parked in an
unused position such as 0 during normal operation to avoid changing the
mode accidently with the paddle switch.
Table 4. Mode Configuration Functions
Function
Switch
Setting
Paddle
Switch Up
Paddle
Switch Down
Function Description
0
–
–
Park position for normal operation (paddle switch has no effect)
1
Auto By,
Auto RC,
3G,
HD,
SD,
or By.
Scroll to Channel 1 input operating mode
2
Scroll to Channel 2 input operating mode
3
Scroll to Channel 3 input operating mode
4
Scroll to Channel 4 input operating mode
5-9
–
–
Not used
A-E
–
–
F
Recall
Recall factory defaults (all channels have Reporting Enabled and
Auto/Mute mode selected).
