36 8943CF — Instruction Manual
Configuration and Monitoring
Table 3. Reported Input/Output Status Summary
Operating
Mode
Input
Carrier
Detect
1
1
When a signal is missing on any input, the red FAULT LED will flash on the front of the module circuit board.
Reclocker
Locked
PRES
LED
3G
LED
HD
LED
SD
LED
Output Reporting
Reported
Input State
Auto Reclock/Bypass Not Present N/A Off Off Off Off N/A
Disabled Not Monitored
Enabled Not Monitored
Auto Reclock/Bypass Present N/A Green Off Off Off Input Signal
Disabled Not Monitored
Enabled Present
Auto Reclock/Bypass Present
Not 270M,
1485Mb/s, or
2970Mb/s
Green Off Off Off Input Signal
Disabled Not Monitored
Enabled Present
Auto Reclock/Bypass Present 270Mb/s Green Off Off Yellow
Reclocked
270Mb/s
Disabled Not Monitored
Enabled Present
Auto Reclock/Bypass Present 1485Mb/s Green Off Green Off
Reclocked
1485Mb/s
Disabled Not Monitored
Enabled Present
Auto Reclock/Bypass Present 2970Mb/s Green Blue Off Off
Reclocked
2970Mb/s
Disabled Not Monitored
Enabled Present
Auto Reclock/Mute Not Present N/A Off Off Off Off Muted
Disabled Not Monitored
Enabled Not Present
Auto Reclock/Mute Present
Not 270M,
1485Mb/s, or
2970Mb/s
Off Off Off Off Muted
Disabled Not Monitored
Enabled Not Present
Auto Reclock/Mute Present 270Mb/s Green Off Off Yellow
Reclocked
270Mb/s
Disabled Not Monitored
Enabled Present
Auto Reclock/Mute Present 1485Mb/s Green Off Green Off
Reclocked
1485Mb/s
Disabled Not Monitored
Enabled Present
Auto Reclock/Mute Present 2970Mb/s Green Blue Off Off
Reclocked
2970Mb/s
Disabled Not Monitored
Enabled Present
Fixed 270M/Mute Not Present N/A Off Off Off Off Muted
Disabled Not Monitored
Enabled Not Present
Fixed 270M/Mute Present Not 270Mb/s Off Off Off Off Muted
Disabled Not Monitored
Enabled Not Present
Fixed 270M/Mute Present 270Mb/s Green Off Off Yellow
Reclocked
270Mb/s
Disabled Not Monitored
Enabled Present
Fixed 1485M/Mute Not Present N/A Off Off Off Off Muted
Disabled Not Monitored
Enabled Not Present
Fixed 1485M/Mute Present Not 1485Mb/s Off Off Off Off Muted
Disabled Not Monitored
Enabled Not Present
Fixed 1485M/Mute Present 1485Mb/s Green Off Green Off
Reclocked
1485Mb/s
Disabled Not Monitored
Enabled Present
Fixed 2970M/Mute Not Present N/A Off Off Off Off Muted
Disabled Not Monitored
Enabled Not Present
Fixed 2970M/Mute Present Not 2970Mb/s Off Off Off Off Muted
Disabled Not Monitored
Enabled Not Present
Fixed 2970M/Mute Present 2970Mb/s Green Blue Off Off
Reclocked
2970Mb/s
Disabled Not Monitored
Enabled Present
