Introduction
The 8943CF can be populated with any of the dual transmitter SFP devices
listed in
Table 1 , depending on the application desired. SFP devices come
in kits containing the SFP device, a mounting bracket, and a fiber cable
assembly. Kit part numbers are indicated by a -K at the end of the part
number. Refer to
Figure 3 on page 14 for a kit example.
The SFP devices are capable of handling bit rates from 143 Mb/s up to
3 Gb/s. Refer to
Table 1 for the current SFP models for use with the 8943CF
modules.
Note This manual shows 8943CF and 8943FC CWDM functionality in conjunction
with the 8939FCA and 8939FCB fiber optic Mux/Demux modules. There are
other applications for CWDM application not covered here.
Table 1. Fiber Optic Dual Transmitter SFP Devices
SFP Device Type Frequencies
SFP-1310-M1DTX-K
Dual Transmitters
1310nm 1310nm SFP-1310-M1DTX
1
1 Spare SFP devices can be purchased without a kit, but initial installation requires the full kit.
SFP-1310-M2DTX 1
SFP-CWDM3G-1-K
1470nm 1490nm
SFP-CWDM3G-1 1
SFP-CWDM3G-2-K
1510nm 1530nm
SFP-CWDM3G-2
1
SFP-CWDM3G-3-K
1550nm 1570nm
SFP-CWDM3G-3
1
SFP-CWDM3G-4-K
1590nm 1610nm
SFP-CWDM3G-4 1
SFP-CWDM3G-5-K
1310nm 1330nm
SFP-CWDM3G-5 1
SFP-CWDM3G-6-K
1350nm 1370nm
SFP-CWDM3G-6 1
SFP-CWDM3G-7-K
1390nm 1410nm
SFP-CWDM3G-7
1
SFP-CWDM3G-8-K
1430nm 1450nm
SFP-CWDM3G-8
1
