24
NOTE:
You must select a writable, uncompressed disk drive. Otherwise, an error can occur during IMC
deployment. To change the compression setting of a disk drive:
• Right-click the disk name and select Properties from the shortcut menu.
• On the General tab of the disk properties window that appears, clear the selection of Compress drive
to save disk space.
• Click OK.
5. On the tip window that appears, click OK.
The Configure Web Service Port window appears, as shown in
Figure 13 .
Figure 13 Configure Web Service Port
6. Set HTTP Port and HTTPS Port.
The default is 8080 and 8443. Make sure the specified ports are open in the system firewall on the
IMC master server and are not being used by another service. If UAM is to be installed for the IMC
system, set HTTP Port to 80. You cannot change the HTTP port number after IMC installation is
completed. To change the HTTP port number, install and deploy IMC again.
7. Click Deploy.
The Deploying window appears, as shown in
Figure 14 .
