10.1.11 Working parameters
*
Fig. 105
Set the farming machine job limits.
*
The item Tank level correction factor is present only if Tank level sensor was selected,
see chapter 9 "Basic settings"
SPRAYING LIMITS
Fig. 106 Fig. 107
• Spraying speed limit
To configure the items on this menu, you must
enable the speed limit:
Limit enabled
Limit disabled
• Minimum spraying speed
Set the minimum spraying speed:
Bravo 400S closes the main valve when the
tractor speed is lower than the set value.
Fig. 108 Fig. 109
• Regulation pressure limit
To configure the items on this menu, you must
enable the pressure limit:
Limit enabled
Limit disabled
• Minimum regulation pressure
Set the minimum spraying pressure:
Bravo 400S blocks the automatic regulation
of the proportional valve when the pressure is
lower than the set value.
Fig. 110
• Flowrate correction factor
When using a paddle flowmeter and the sprayed fluid has a different viscosity than that of water, the
computer could display wrong measurements; to correct them change the flowrate correction factor:
• if at the end of the spraying the tank still contains fluid, reduce the factor;
• if the fluid finishes before the job has ended, increase the factor.
Flowmeters of the ORION series (code 462xxx) are not affected by the viscosity difference of
the fluids: set the factor to 1.00.
Fig. 111
• Tank level correction factor
If the sprayed fluid is lighter than water, the device may indicate wrong measurements; to correct this
measurement, edit the sprayed liquid weight, referred to 1 liter of product.
