3.2 DESIGN AND OPERATING FEATURES
• The adjustable precision 90° vee bearings pre-load and stabilize the rotating
head to provide long life, low maintenance, stability, and precision.
• The Clamshell splits into two halves for mounting on closed loop systems.
• All parts are secured to the two halves, thus avoiding the loss of parts and at
the same time providing maximum ease of handling
• The Clamshell is equipped with jackscrews and adjustable mounting bars for
out-of-round pipe conditions.
• Dual tool blocks with auto-feed sprockets and adjustable slides provide
maximum maintainability, life, and operator safety, with a minimum of operator
training.
• The gear reduction, auto-feed sprockets provide .0025” (.06 mm) of radial
feed per revolution of the Headstock for a controlled depth of cut.
• The drive gears and bearing surfaces are covered for operator safety.
• The drive gears and bearing surfaces are sealed to protect from dust and
chips.
• For the safety of the operator, the controls are away from the rotating
Headstock.
• The modular design is easy to maintain and has drive and tooling options.
• The detachable air, electric, or hydraulic motors are easy to handle and have
low axial clearance.
