7
Model 614RBL thru 642RBL Clamshells
92-0480 : Rev. 130916
3. GENERAL DESCRIPTION
The Model 600RBL Low Profile Clamshells are a split-frame pipe lathe designed to sever
and bevel in-line pipe.
Use standard Tool Blocks to configure the Model 600RBL Clamshells for the following
operations:
• Sever in-line pipe
• Sever and bevel in-line pipe
• Sever and double bevel in-line pipe
The following items are included with each Clamshell:
• Dual Air or Hydraulic Motors
• Spacer Bars to cover the range of pipe sizes listed in Section 4.1
• Jackscrews
• Two (2) Tool Modules
• One (1) Tripper Bracket Assembly
3.1 PART NUMBERS FOR THE MODEL 600RBL CLAMSHELL SERIES
MODEL 600RBL CLAMSHELL SERIES STANDARD PART NUMBERS
Part Number Model Power*
01-1600 614RBL Single Air
01-1602 614RBL Single Hydraulic
01-1610 616RBL Single Air
01-1612 616RBL Single Hydraulic
01-1620 620RBL Single Air
01-1622 620RBL Single Hydraulic
01-1630 624RBL Single Air
01-1632 624RBL Single Hydraulic
01-1640 630RBL Single Air
01-1642 630RBL Single Hydraulic
01-1690 636RBL Single Air
01-1692 636RBL Single Hydraulic
01-2089 642RBL Single Air
01-2091 642RBL Single Hydraulic
* NOTE: Options for Dual Air motor or Dual Hydraulic motor are available as standard
products. Contact Tri Tool Inc. for more information.
