Model 614RBL thru 642RBL Clamshells
92-0480 : Rev. 130916
9. TOOL BITS
9.1 SEVER TOOL BIT SET
Use this Sever Tool Bit Set to sever a pipe with up to 1 3/8” (34.9 mm) wall with a
1/4” (6.4 mm) wide cut.
Item Part
No. No. Description Qty
1. 30-0225 SPACER, TOOL, 3/4” X 1” X 3” 2
2. 30-0310 SPACER, TOOL, 3/4” X 3/4” X 3” 2
3. 99-1209 TOOL BIT, LEADING SEVER 1
4. 99-1210 TOOL BIT, TRAILING SEVER 1
2
3
4
2
Tool Block No. 2
Tool Block No. 1
1
1
