6.6 SELECTION AND INSTALLATION OF THE TOOL BIT SET

See section 9 for a description of Tool Bit Sets. This section has the installation

drawings of the Tool Bit Set-Up.

1. Ensure that the wall thickness plus 3/4” (19.0 mm) of Tool Bit protrudes from

the end of the Tool Holder.

2. Tighten the Tool Bit Set Screws.
3. To check that there is adequate radial clearance, do a full rotation of the

Headstock.

4. Check that the Leading Tool Bit contacts the pipe approximately .020”

(.51 mm) to .040” (1.02 mm) before the Trailing Tool Bit.

CAUTION

CAUTION: Do not touch the tool bits with your hands. The tool bits

are very sharp and can cut or puncture your skin. Be sure to use

gloves when you handle tool bits
CAUTION: Do not use dull tool bits or tool bits that are not made by

Tri Tool Inc. If you use these bits the Clamshell may perform poorly.

This constitutes abuse of the equipment and may void the warranty.
