Model 614RBL thru 642RBL Clamshells
92-0480 : Rev. 130916
Parts List, HD Electric Drive Kit, 115V (P/N 05-0465)
Item Part
No. No. Description Qty
58-0167 MOTOR ASSY, ELECTRIC DRIVE, 115V 1
1. 27-0826 ADAPTER, DRIVE 1
2. 30-3143 1/2" SQUARE DRIVE 1
3. 33-0055 SCREW, CAP 5/16-18 X 7/8" LG. 3
4. 33-0057 SCREW, CAP 5/16-18 X 1 1/4" LG. 1
5. 33-1874 SCREW, ANTI-ROTATION 2
6. 58-0192 MOTOR, ELECTRIC, 110V ,MODIFIED 1
7. 27-1137 ADAPTER, MOTOR 1
8. 33-0988 SCREW, SHOULDER, 1/2" X 1/2" 1
Parts List, HD Electric Drive Kit, 230V (P/N 05-0466)
Item Part
No. No. Description Qty
58-0174 MOTOR ASSY, ELECTRIC DRIVE, 230V 1
1. 27-0826 ADAPTER, DRIVE 1
2. 30-3143 1/2" SQUARE DRIVE 1
3. 33-0055 SCREW, CAP 5/16-18 X 7/8" LG. 3
4. 33-0057 SCREW, CAP 5/16-18 X 1 1/4" LG. 1
5. 33-1874 SCREW, ANTI-ROTATION 2
6. 58-0173 MOTOR, ELECTRIC, 110V ,MODIFIED 1
7. 27-1137 ADAPTER, MOTOR 1
8. 33-0988 SCREW, SHOULDER, 1/2" X 1/2" 1
